Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
USF56F 84591 |
$79.00 | 0.562" | 5.187" |
15-Aluminum was 6-Aluminum |
56 | 56 | 56 | |||
USF182U 108604 |
$180.00 | 0.875" | 5.750" | 8-Aluminum | ||||||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
USF143T 141809 256208 |
$74.50 | 0.687" | 5.625" | 12-Plastic | 56T | 56T | 56T | |||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
US399405 W/KEY 399405 casting: 375621 |
$82.00 |
0.875" w/ key |
9.000" | 14-Plastic | ||||||
US375621 W/KEY 399405 |
$124.00 | 0.875" | 9.000" | 14-Plastic | ||||||
USF2134T 193489, 360373, 378427 |
$102.00 | 1.125" | 9.375" | 8-Plastic | 210T | 210T | ||||
USF2542T W/KEY 399405 347273, 523551, 528680, 528680 |
$197.50 | 1.250" | 9.000" | 14-Plastic | 250T | 250T | 250T | |||
US347274 W/KEY 399405, 347274 |
$256.50 |
1.250" w/ key |
10.500" | 14-Plastic | ||||||
USF2544T 171602 |
$255.00 | 1.250" | 11.000" | 14-Plastic | 250T | 250T | ||||
US370427 370427 |
$280.50 | 1.375" | 8.000" | 14-Plastic | ||||||
US370428 370428 |
$280.50 | 1.375" | 11.125" | 14-Plastic | 250T | |||||
|
||||||||||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
USF2842 76274, 375603 |
$279.50 |
1.625" w/ 0.250" keyway |
9.000" | 18-Plastic | 280T | |||||
US378428 378428 |
$179.00 | 1.750" | 9.500" | 8-Plastic | ||||||
USF3242 76259, 375605 |
$195.00 |
1.875" w/ 0.375" keyway |
9.000" | 18-Plastic | 320T | |||||
US375606 375606, USF3602T |
$213.00 |
2.125" w/ 0.375" keyway |
8.500" | 16-Plastic | 360T | |||||
USF4042 113396, 375604 |
$114.50 |
2.375" w/ 0.375" keyway |
10.750" | 12-Plastic | 400T | |||||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
USF182T 360240 |
$82.00 | 0.875" | 6.750" | 8-Plastic | 180T | |||||
US399407 W/KEY 399407 casting: 360240 |
$82.00 |
0.875" w/ key |
||||||||
USF2134U 360985, 399408 W/KEY, 522172 |
$86.00 | 0.875" | 8.000" | 8-Plastic | 180T | 180T | ||||
US399408 w/key 399408 W/KEY, 360985 |
$89.50 |
0.875" w/ key |
||||||||
USF2132T 183821, 360276 |
$160.00 | 1.125" | 6.750" | 8-Plastic | 180T | |||||
US360298 360298, W/KEY, 399407 |
$153.00 | 7.250" | 8-Plastic | |||||||
USF2844 76176, 362253 |
$255.50 | 1.625" | 10.375" | 10-Plastic | 280T | 280T | ||||
USF3244 76313, 362254 |
$316.50 | 1.875" | 13.250" | 12-Plastic | 320T | 320T | ||||
USF3644 110900, 362255 |
$399.50 | 2.125" | 14.000" | 12-Plastic | 360T | 360T | ||||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
USF4044 111679, 375607 |
$506.50 |
2.375" w/ 0.390" kayway |
15.875" | 12-Plastic | 400T | 400T | ||||
USF4444 105312, 375880 |
$496.00 | 17.875" | 16-Plastic | 440T | 440T | |||||
USF4494 375882 |
$515.00 | 19.875" | 16-Plastic | 449T | 449T | |||||
Part | Price | Bore (ID) | OuterDiameter | Blades-Material | Notes | |||||
US369160 369160 |
$154.50 |
0.875" no key |
6.000" | 8-Plastic | One bolt clamp | |||||
US399406 369161, W/KEY 399406 |
$82.00 |
0.875" w/ key |
6.000" | 8-Plastic | One bolt clamp | |||||
US369161 369161, W/KEY 399406 |
$135.00 |
1.125" no key |
6.000" | 8-Plastic | One bolt clamp | |||||
US375602 375602, W/KEY 463042 |
$195.00 |
1.220" no key |
7.250" | 8-Plastic | Two bolt clamp | |||||
US463042 375602, W/KEY 463042 |
$82.00 |
1.220" w/ key |
7.250" | 8-Plastic | Two bolt clamp | |||||
US992934 603 |
$182.50 |
1.625" w/ 0.250" keyway |
7.500" | 16-Plastic, 2 are short | Two bolt clamp | w/keyway | ||||
US992936 375606 |
$180.00 |
2.125" w/ 0.375" keyway |
7.000" | 16-Plastic, 2 are short | Two bolt clamp | |||||
