| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN143F | $62.50 | 0.625" | 5.875" | 9-Plastic | 56 | 56 | 56 | |||
|
||||||||||
| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN656F | $22.50 | 0.687" | 5.375" | 13-Aluminum | 56 | 56 | 56 | |||
| CN656FA | Obsolete | 0.812" | 5.275" | 13-Aluminum | 56 | 56 | 56 | |||
|
|
||||||||||
| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN213TZ | $97.50 | 1.750" | 7.625" | 11-Aluminum | 213 | 213 | 213 | |||
| CN215TZ | $132.50 | 2.343" | 7.625" | 11-Aluminum | 215 | 215 | 215 | |||
|
|
||||||||||
| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN182F | $60.00 | 0.625" | 7.750" | 9-Aluminum | 180 | 180 | 180 | |||
| CN213F | $195.00 | 1.125" | 9.875" | 9-Aluminum | 210 | 210 | 210 | |||
| CN2542 | $75.00 | 1.375" | 8.500" | 10-Aluminum | 250 | 250 | 250 | |||
| CN2544 | $100.00 | 1.375" | 11.000" | 10-Aluminum | 250 | 250 | 250 | |||
| CN2842 | $80.00 | 1.625" | 10.000" | 10-Aluminum | 280 | 280 | 280 | |||
| CN2844 | $149.00 | 1.625" | 12.500" | 10-Aluminum | 280 | 280 | 280 | |||
| CN3242 | $80.00 | 1.625" | 10.125" | 15-Aluminum | 320 | 320 | 320 | |||
| CN3244 | $250.00 | 1.625" | 14.250" | 15-Aluminum | 320 | 320 | 320 | |||
| CN3642 | $125.00 | 2.000" | 11.125" | 15-Aluminum | 360 | 360 | 360 | |||
| CN4042 | $295.00 | 2.375" | 12.000" |
12-Aluminum was 15-Aluminum |
400 | 400 | 400 | |||
| CN3644 | $350.00 | 2.375" | 13.875" | 15-Aluminum | 360 | 360 | 360 | |||
| CN4044 | $439.00 | 2.375" | 17.125" | 15-Aluminum | 400 | 400 | 400 | |||
| CN4444 | $657.00 | 2.375" | 18.125" | 15-Aluminum | 440 | 440 | 440 | |||
|
|
||||||||||
| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN1137 | $17.50 | 0.675" | 4.800" |
13-Plastic w/metal insert |
||||||
|
|
||||||||||
| Part | Price | Bore (ID) | Diameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| CN143FTC | $22.50 |
0.625" diameter with 0.500" across two flat spots |
6.000" | 9-Plastic | ||||||
|
