Reliance Fans Harmonization Schedule (HS) and Schedule B Number: 85030090 Plastic Fans Aluminum Fans All fans by Size Allis-Chalmers Baldor Century Doerr Fincor Franklin General Electric Leeson Leroy Somer Lincoln Louis-Allis Magnetek Marathon Reliance Siemens Siemens-Allis AO Smith Toshiba US Motors Westinghouse Weg |
||||||||||
|
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF182F | $110.00 | 0.625" | 7.500" | 9-Plastic | 180T | 180T | 180T | |||
|
REF182FD 78547-1 K |
$152.50 |
0.625" w/ 0.250" keyway |
9.000" | 9-Plastic | 210T | 210T | 210T | |||
| REF182FA | $225.00 | 0.875" | 7.500" | 9-Plastic | 180T | 180T | 180T | |||
| REF213FA | $125.00 | 0.875" | 9.000" | 9-Plastic | 210T | 210T | 210T | |||
| REF254F | $CALL | 0.875" | 10.500" | 13-Plastic | 250T | 250T | ||||
|
REF182FE 702664-1 A Confirm measurements at right |
$376.50 | 0.937" | 4.750" | 9-Plastic | 180T | |||||
|
REF182FB 702664-1 G |
$48.50 | 0.937" | 7.500" | 9-Plastic | 180T | 180T | 180T | |||
| REF213FF | $CALL | 1.125" | 4.750" | 9-Plastic | 210T | |||||
|
REF252F 702664-1 A Confirm measurements at right |
$169.50 | 1.125" | 5.750" | 9-Plastic | 250F | |||||
| REF254FH | $CALL | 1.125" | 7.375" | 9-Plastic | 250T | 250T | ||||
|
REF213FB 78547-1 P |
$242.50 |
1.125" w/ 0.240" keyway |
9.000" | 9-Plastic | 210T | 210T | 210T | |||
| REF254FA | $CALL | 1.125" | 10.500" | 13-Plastic | 250T | 250T | 250T | |||
| REF284F | $CALL | 1.125" | 11.750" | 13-Plastic | 280T | 280T | 280T | |||
|
REF182FC 78546-1 G |
$198.50 |
1.156" w/ 0.312" keyway |
7.500" | 9-Plastic | 180T | 180T | 180T | |||
|
REF213FC 78547-1 M |
$116.50 |
1.156" w/ 0.250" keyway |
9.000" | 9-Plastic | 210T | 210T | 210T | |||
|
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF4001A | $175.00 | 1.250" | 5.625" | 9-Plastic | ||||||
| REF254FB | $CALL | 1.250" | 10.500" | 13-Plastic | 320T | |||||
| REF324F | $CALL | 1.250" | 13.500" | 13-Plastic | 320T | 320T | ||||
| REF213FD | $CALL | 1.375" | 9.000" | 9-Plastic | ||||||
| REF254FC | $CALL | 1.375" | 10.500" | 13-Plastic | ||||||
| REF282F | $160.00 | 1.625" | 5.750" | 9-Plastic | 280T | |||||
|
REF702675-1A 702675 1A Confirm measurements are right |
$165.00 |
1.625" w/ 0.375" keyway |
7.000" | 9-Plastic | ||||||
|
REF360FB 702675 1A Confirm measurements are right |
$41.50 |
1.625" w/ 0.375" keyway |
7.500" | 9-Plastic | 280T | 360T | ||||
| REF213FE | $CALL | 1.625" | 9.000" | 9-Plastic | 250T | |||||
| REF213FF | $CALL | 1.625" | 9.000" | 9-Plastic | 280T | 320T | 445T | |||
| REF254FD | $CALL | 1.625" | 10.500" | 13-Plastic | 250T | 250T | 250T | |||
| REF288 | $CALL | 1.625" | 11.750" | 13-Plastic | ||||||
| REF366 | $295.00 | 1.625" | 13.500" | 13-Plastic | 360T | |||||
|
REF254FG 78548-1 F 78548-1 P |
$217.50 |
1.750" w/ 0.250" keyway |
10.500" | 13-Plastic | 280T | |||||
|
REF284FA 78549-1 H |
$431.50 | 1.750" | 11.750" | 13-Plastic | 280T | 280T | ||||
|
REF702674-1C 702674 1C |
$81.50 |
1.875" w/ 0.250" keyway |
5.750" |
9-Plastic 1.600" tall |
||||||
|
REF254FK 78548-1 K |
$123.50 | 10.500" | 13-Plastic | 280T | ||||||
| REF254FE | $CALL | 1.875" | 11.500" | 13-Plastic | 360T | |||||
|
REF78550-1M 78550-1 M |
$131.50 |
1.875" w/ 0.250" keyway |
13.500" | 13-Plastic | ||||||
|
REF360F 78550-1 F |
$157.50 | 15.500" | 13-Plastic | 360T | 360T | |||||
|
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
|
REF447D 702674 1D |
$55.00 |
2.000" w/ 0.250" keyway |
5.750" | 9-Plastic | ||||||
|
REF440D 702675 1D |
$125.00 | 7.500" | 9-Plastic | |||||||
|
REF324FC 78548-1 R |
$184.00 | 10.500" | 13-Plastic | 320T | ||||||
| REF449 | $CALL | 11.750" | 13-Plastic | 449T | ||||||
|
REF324FA 78550-1H |
$146.50 | 13.500" | 13-Plastic | 320T | 320T | |||||
|
REF444F 78557-1E |
$560.50 | 15.500" | 13-Plastic | 444T | ||||||
|
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
|
REF145 79327-11A |
$99.50 | 0.625" | 5.562" | 13-Plastic | 145T | |||||
|
REF56F 79327-10-A |
$27.50 | 0.625" | 5.875" | 13-Plastic | 56T | 56T | 56T | |||
|
REF79327-10-B 78327-10-B |
$27.50 |
0.875" w/ 0.187" key |
5.875" | 13-Plastic | ||||||
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF143F | $CALL | 0.625" | 6.375" | 13-Aluminum | 140T | 140T | 140T | |||
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF182FE | $CALL | 0.875" | 7.000" | 9-Plastic | 180T | 180T | 180T | |||
| REF212F | $CALL | 0.875" | 8.625" | 9-Plastic | 210T | 210T | 210T | |||
| REF254FJ | $CALL | 0.875" | 10.000" | 15-Plastic | 250T | 250T | ||||
| REF282 | $CALL | 1.125" | 10.000" | 15-Plastic | 280T | |||||
| REF322 | $CALL | 1.250" | 10.000" | 15-Plastic | 320T | |||||
|
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF284FB | $CALL | 1.125" | 11.375" | 15-Plastic | 280T | 280T | ||||
| REF324FB | $CALL | 1.250" | 13.500" | 15-Plastic | 320T | 320T | ||||
| REF443H | $CALL | 1.375" | 11.625" | 15-Plastic | ||||||
| REF324FB | $CALL | 1.750" | 13.500" | 15-Plastic | ||||||
| REF360FA | $CALL | 1.875" | 11.375" | 15-Plastic | 360T | |||||
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
| REF364 | $649.50 | 1.875" | 15.375" | 13-Aluminum | 260T | 360T | ||||
| REF404FA | $603.90 | 2.250" | 9.750" | 10-Aluminum | 400T | |||||
| REF404FB | $CALL | 2.250" | 16.750" | 15-Aluminum | 400T | 400T | ||||
| REF442FM | $CALL | 2.437" | 9.750" | 10-Aluminum | 440T | |||||
| REF444FM | $CALL | 2.437" | 16.750" | 15-Aluminum | 440T | |||||
| REF446FM | $CALL | 2.437" | 20.250" | 15-Aluminum | 440T | |||||
|
||||||||||
| Part | Price | Bore (ID) | OuterDiameter | Blades-Material | 1200rpm frame | 1800rpm frame | 3600rpm frame | |||
|
REF446FP2.0 702618 4C |
$275.00 |
2.000" w/ 0.250" keyway |
17.500" | 15-Plastic | 440 | |||||
|
REF404FP 702618 4A |
$275.00 |
2.437" w/ 0.500" keyway |
17.500" | 15-Plastic | 400T | 400T | ||||
| REF446FP | $CALL | 2.437" | 20.062" | 15-Plastic | 440T | |||||
|
